Serial SPI Small OLED Display Module 192x64dots
Product Description
1. 192x64dots
2. Parallel interface
3. Ultra high contrast, YG & White LED backlight as option
4. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option
| Item | Description |
| Product Name | 192x64dots Graphic LCD Module |
| Model No. | RY19264 |
| Dot Format | 192x64 |
| Outline (mm) | 135*65 |
| Viewing Area(mm) | 6:00 |
| Pixel Size( mm) | 0.43 x 0.42 |
| Viewing Angle | 6 O' clock |
| LCD Type | FSTN-Positive, STN-Gray |
| Backlight | White or Amber LED backlight |
| Driver IC | ST7586S |
| Power supply | 3.3V |
| Interface | Parallel |
| Operating Temp | -20º C~70ºC |
| Storage Temp | -30º C~80ºC |
Application
Why choose Royal Display?
WHY CHOOSE ROYAL DISPLAY?
1. Best Quality
---THREE times of inspection on all products on production:
Step 1: Raw Material check
Step 2: Process check and full inspection after wire bonding&chip bonding
Step 3: full test before packaging and partial check before shippment
2. Best Price
---manufacturer
---best suppliers sources
---all products by oneself
3.Company strength
---good quality&competitive price
---Listed company
---Management System: ISO 9001:2015
4.Rich experiences
---Over 10 years experiences in Lcd display field.
Custom Made Project Order Flow
1. Enquiry
Send us draft / details drawing, project schedule, application, qty. demand, etc by email ( to wendy@rylcd.com)
Quotation will be ready within 3 days ( normally 1 day).
2. Counter drawing
We will send out counter drawing after confirm of our quotation and received the tooling charge.
normally, 3 days for LCD glass and 1 week for LCD module.
3. Tooling samples
After drawing approval, tooling samples will be finished around 30 days
4. Mass production
After samples approval, mass production goods will be finished around 30 to 60 days. Depends of the order situation and materials supply siutuation.
APPLICATION
