192X64 UC1698 Positive Transflective LCD Display FPC FSTN Parallel

Brand Name : Royal Display

Model Number : RY19264

Certification : SGS ROHS

Place of Origin : CHINA

MOQ : 500pcs

Price : Negotiable

Payment Terms : D/A, L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 300K/M

Delivery Time : 15-20 work days

Packaging Details : Cartons, Capboard, EPE, Blister Tray

DOT Format : 192X64

Outline (mm) : 135X65

Backlight Color : White

Power Supply : 3.3V

IC Package : COB

Viewing Direction : 6:00

Appearance : White on Black

Connector : FPC

Display Type : FSTN

Interface : Parallel

Operating Temp. : -20º C~70ºC

Storage Temp. : -30º C~80ºC

Contact Now

Positive Transflective Custom LCD Display In Stock 192x64 Resolution

PRODUCT DESCRIPTION
1. 192x64dots
2. Parallel interface
3. Ultra high contrast, YG & White LED backlight as option
4. STN-YG, STN-blue, STN-Gray, FSTN-Positive display results as option

Item Description
Product Name 192x64dots Graphic LCD Module
Model No. RY19264
Dot Format 192x64
Outline (mm) 135*65
Viewing Area(mm) 6:00
Pixel Size( mm) 0.43 x 0.42
Viewing Angle 6 O' clock
LCD Type FSTN-Positive, STN-Gray
Backlight White or Amber LED backlight
Driver IC ST7586S
Power supply 3.3V
Interface Parallel
Operating Temp -20º C~70ºC
Storage Temp -30º C~80ºC

ACCESSORIES

Royal Display can provide many accessories to go with your display. If you would like to source a connector, cable, test jig or other accessory preassembled to your LCD (or just included in the package), our team will make sure you get the items you need. Get in touch with a team member today to accessorize your display!

192X64 UC1698 Positive Transflective LCD Display FPC FSTN Parallel

WARRANTY


Royal Display offers the original purchaser who has purchased a product from the lcd module tft a limited warranty that the product (including accessories in the product's package) will be free from defects in material or workmanship.

Product Packing Process

192X64 UC1698 Positive Transflective LCD Display FPC FSTN Parallel
